Phoenix Series
Premium Auditorium Light Solution
The Phoenix Series by Aniston is a high-performance range of professional profile lights designed for auditoriums, stages, and architectural applications. With advanced optics, exceptional brightness, and superior color accuracy, it transforms any performance or presentation space.
- High CRI for True Colors: Delivers up to 95 CRI for lifelike color reproduction, perfect for professional environments.
- Customizable Beam Control: Adjustable beam angles and three beam width options: Fusion (50mm), Phoenix (100mm), and Phoenix Plus (150mm).
- Energy-Efficient LED Performance: High-efficiency SMD LEDs with up to 120 lm/W, reducing power consumption without compromising brightness.
- Seamless Dimming & Control: Compatible with DMX, DALI, 0-10V, and TRIAC systems for flexible lighting control.
- Flexible Installation Options: Supports surface, recessed, and suspended installations with customizable finishes.
Product Features
- Sleek and modern profile design, perfect for architectural and auditorium lighting applications.
- High-efficiency LED technology providing excellent luminous output with low energy consumption.
- Exceptional color rendering index (CRI) ensuring true-to-life color representation.
- Customizable lengths and configurations to suit diverse design and installation requirements.
- Advanced thermal management system for enhanced longevity and consistent performance.
- Wide range of beam angles for tailored light distribution and optimal coverage.
- Dimmable options available for precise lighting control and ambiance creation.
- Sturdy and lightweight aluminum profile ensuring durability and ease of installation.
- Compatible with various control systems for seamless integration into smart lighting setups.
- Ideal for auditoriums, conference halls, and other high-end commercial spaces.
Technical Specifications
| Parameter | Fusion | Phoenix | Phoenix Plus |
|---|---|---|---|
| Model Number | PHO1116510S | PHO013050S | PHO013050SP |
| Type | Linear LED Light | ||
| Application | Indoor / Architectural / Commercial | ||
| Luminaire Length | 3050 mm | ||
| Luminaire Width | 50 mm | 100 mm | 150 mm |
| Body Material | Aluminum / Polycarbonate | ||
| Finish | Matte White / Black / Custom Color | ||
| Installation Type | Surface / Recessed / Suspended | ||
| LED Type | High-Efficiency SMD LEDs | ||
| Colour Options | WW / NW / CW | ||
| CCT (Colour Temp.) | CCT Tunable (2700K - 6500K) | ||
| CRI (Colour Rendering Index) | 95 | ||
| Luminous Efficacy (lm/W) | ≥ 120 lm/W | ||
| Beam Angle | 120° | ||
| Wattage | 30W/m | 50W/m | 90W/m |
| Operating Voltage | AC 100-277V, 50/60Hz | ||
| Driver Type | Dimmable / DALI / 0-10V / TRIAC | ||
| Power Factor | ≥0.98 | ||
| Efficiency | >95% | ||
| THD | <5% | ||
Technical Diagram
Resources & Manuals
Phoenix Series Datasheet
DownloadSoftware & Downloads
DIALux Software
DownloadMain Features
Superior Light Performance
The Phoenix Series offers exceptional luminous efficacy of ≥120 lm/W and a high CRI of 95, ensuring brilliant illumination with true-to-life color accuracy.
Flexible CCT Tunability
With a wide CCT range from 2700K to 6500K, the Phoenix Series adapts to diverse lighting environments, providing warm, neutral, and cool white options.
Versatile Installation Options
Designed for flexibility, the Phoenix Series supports surface, recessed, and suspended mounting, making it ideal for architectural and commercial spaces.
Innovative Lighting for Modern Architectural Spaces
The Phoenix Series redefines lighting excellence with its high-performance, energy-efficient design. Perfect for auditoriums, conference halls, and commercial venues, it offers exceptional illumination with a high CRI of 95 and CCT tunability from 2700K to 6500K. Its sleek profile and adaptable mounting options make it an ideal solution for diverse architectural needs.
Advanced Performance with Smart LED Technology
The Phoenix Series stands out with its superior light efficacy of ≥120 lm/W and a power range from 30W/m to 90W/m, delivering brilliant and consistent illumination. Its high-efficiency SMD LEDs ensure energy savings without compromising light quality, making it the perfect choice for modern, dynamic environments.
